The Lowara ecocirc XLplus 32-120F (220) is a cast iron, high-efficiency wet rotor circulator for heating, chilled water and air-conditioning systems. It has DN32 flanged (PN6/PN10) connections, a 220 mm port-to-port length and up to 12 m of head from a 230V single-phase supply.
An electronically commutated permanent magnet motor and built-in controls match pump output to system demand, with set-up from the front display — no advanced programming needed.
Key features
Proportional pressure, constant pressure and constant speed modes
Constant temperature and differential temperature control
Night mode to cut power when heating load is low
Dry-run protection and air purge function
Digital display with push-button setting
Built-in Modbus RTU and BACnet communication for BMS
Insulation shell supplied for heating applications
Liquid temperature range −10 °C to +110 °C
Typical applications
Commercial and large domestic heating systems
Chilled water and air-conditioning circuits
Replacing Grundfos MAGNA/UPS and Wilo Stratos pumps of similar duty
Channel Island Pumps supplies genuine Lowara circulators to installers, facilities teams and homeowners across Jersey and Guernsey. Not sure this is the right size? Send us the model on your existing pump, or your system's flow and head, and we'll match it for you. Prices are shown excluding GST; Jersey GST is added at checkout.
